API Feature
Security
Rate Limiting Configuration
Protect your cluster with configurable rate limits at multiple levels: IP, user, API key, and endpoint.
Rate limiting decision tree with multiple check layers
Rate Limit Layers
IP-based
First line of defense against abuse:
- • Anonymous request limits
- • DDoS protection
- • Applies before auth
User-based
Per-account limits:
- • Based on user ID
- • Tier-based quotas
- • Cross-device tracking
API Key-based
Programmatic access limits:
- • Per-key quotas
- • Scope-specific limits
- • Independent of user limits
Endpoint-based
Per-route limits:
- • Search: high limits
- • Write: lower limits
- • Admin: strict limits
Algorithm
MLGraph uses a sliding window rate limiter with token bucket burst handling. This provides smooth rate limiting without the boundary issues of fixed windows.
Configuration Parameters
| Parameter | Description | Example |
|---|---|---|
| requestsPerMinute | Sustained request rate | 1000 |
| burstLimit | Max concurrent burst | 100 |
| windowSize | Sliding window duration | 60s |
| penaltyDuration | Backoff after limit hit | 30s |
Response Headers
HTTP/1.1 200 OK
X-RateLimit-Limit: 1000
X-RateLimit-Remaining: 847
X-RateLimit-Reset: 1703246400
X-RateLimit-Bucket: api-key:mlg_xxx
# When rate limited:
HTTP/1.1 429 Too Many Requests
Retry-After: 30
X-RateLimit-Limit: 1000
X-RateLimit-Remaining: 0
X-RateLimit-Reset: 1703246400
Content-Type: application/json
{
"error": "rate_limit_exceeded",
"message": "Too many requests. Retry after 30 seconds.",
"retryAfter": 30,
"limit": 1000,
"window": "1m"
}Configuration Example
// DaemonConfig rate limiting section
{
"rateLimiting": {
"enabled": true,
"storage": "redis", // or "memory"
"global": {
"requestsPerMinute": 10000,
"burstLimit": 500
},
"perIp": {
"requestsPerMinute": 100,
"burstLimit": 20,
"whitelist": ["10.0.0.0/8"]
},
"perUser": {
"free": { "requestsPerMinute": 60 },
"pro": { "requestsPerMinute": 1000 },
"enterprise": { "requestsPerMinute": 10000 }
},
"perEndpoint": {
"/api/search": { "requestsPerMinute": 1000 },
"/api/vectors": { "requestsPerMinute": 100 },
"/api/admin/*": { "requestsPerMinute": 10 }
}
}
}Best Practices
- • Set IP limits lower than user limits (anonymous < authenticated)
- • Use burst limits for traffic spikes, not sustained load
- • Monitor 429 responses to tune limits
- • Whitelist internal services and monitoring
